Trek
Madone SLR 7 7e Gén
2026BMX - Race
Madone SLR 7 7e Gén Data
- Frame
- Carbon
- Suspension
- None
- Gears
- 24
- Weight
- 7.48 kg
- Sizes
- 47, 54, 56, 58, 52, 50, 60, 62
- Colors
- Deep Smoke, Azure, Satin Quicksilver, Axinite Flip/Trek Black, Viper Red, Metallic Red Smoke To Red Carbon Smoke
Looking for replacement tires?
View verified compatible tires for the 2026 Madone SLR 7 7e Gén.
Components
Complete component specification list for this variant.
Drivetrain
Front
Front Derailleur
Shimano Ultegra R8150 Di
- Gears
- 2
Front Shifter
Shimano Ultegra R8170 Di2
Rear
Rear Derailleur
Shimano Ultegra R8150 Di2
- Gears
- 12
Rear Shifter
Shimano Ultegra R8170 Di2
Chainring
Shimano Ultegra R8100
- Gears
- 2
- Ring 1
- 52 Teeth
- Ring 2
- 36 Teeth
Cassette
Shimano Ultegra R8101
- Number of sprockets
- 12
- Range
- 11-30
Chain
Shimano Ultegra/XT M8100
- Gears
- 12
Battery
Shimano BT-DN300
Crank
Shimano Ultegra R8100
Bottom Bracket
Praxis, T47 threaded
Cockpit
Grips
Bontrager Supertack Perf tape
Stem
Madone Integrated
Handlebar
Madone Integrated
Wheels
Front
Front Tire
Bontrager R3 Hard-Case Lite (700, 25mm)
- Size
- 700
- Width
- 25mm
Front Wheel
Bontrager Aeolus Pro (12x100mm)
- Axle Dimension
- 12x100mm
- Rim height
- 51 mm
- Material
- OCLV Carbon
- Position
- front
Rear
Rear Tire
Bontrager R3 Hard-Case Lite (700, 25mm)
- Size
- 700
- Width
- 25mm
Rear Wheel
Bontrager Aeolus Pro (12x142mm)
- Axle Dimension
- 12x142mm
- Rim height
- 51 mm
- Material
- OCLV Carbon
- Position
- back
Brakes
Front
Front Brake
Hydraulic Shimano Ultegra disc
Front Disc
Shimano MT800
Rear
Rear Brake
Hydraulic Shimano Ultegra disc
Rear Disc
Shimano MT800
Seat
Saddle
Bontrager Aeolus Elite
Seatpost
Madone aero seatpost
- Material
- Carbon
Frame
Frame
Series 800 OCLV , KVF (Kammtail Virtual Foil) tube shape, IsoFlow seat tube
- Rear Axle Dimension
- 142x12mm
- Material
- Carbon
Fork
Madone KVF full carbon
Accessories
Chainguard
3S aero chain keeper
