Specialized
Tarmac SL8 Frameset
2026Road - Race
Tarmac SL8 Frameset Data
- MSRP
- USD 3499.99
- Frame
- Carbon
- Weight
- 1.69 kg
- Sizes
- 54, 56, 58, 61, 49, 52, 44
- Colors
- Satin Carbon, Red Pearl / Metallic White Silver
Components
Complete component specification list for this variant.
Seat
Seatpost
S-Works Tarmac SL8 seat post, FACT , 15mm offset
- Length
- 380 mm
- Material
- Carbon
Seatpost Clamp
Integrated Tarmac wedge
Frame
Frame
Threaded Tarmac SL8 FACT 10r , Rider First Engineered™, Win Tunnel Engineered, Clean Routing, BB
- Rear Axle Dimension
- 12x142mm
- Tyre clearance
- 32 65
- Material
- Carbon
Fork
FACT 10r Carbon, flat-mount disc
- Front Axle Dimension
- 12x100mm
Cockpit
Stem
Integrated Tarmac stem, 6-degree
Drivetrain
Bottom Bracket
Threaded 68mm bottom bracket
- Standard
- Threaded
Comparison
Compare specifications and components across all variants of this model. Toggle years to customize your comparison.
Model Year:
| Current Tarmac SL8 Frameset 2026 CurrentCurrentSpecialized Tarmac SL8 Frameset 2026 |  S-Works Tarmac SL8 2026 |  Tarmac SL7 Sport 2026 |  Tarmac SL8 Comp 2026 |  Tarmac SL8 Expert 2026 |  Tarmac SL8 Frameset LTD - Demi Dreaming 2026 |  Tarmac SL8 Frameset LTD - Yoon Hyup 2026 |  Tarmac SL8 Pro 2026 | |
|---|---|---|---|---|---|---|---|---|
| Specifications | ||||||||
| MSRP | USD 3499.99 | USD 13499.99 | USD 3299.99 | USD 4699.99 | USD 6599.99 | USD 5999.99 | USD 5699.99 | USD 8499.99 |
| Frame | Carbon | Carbon | Carbon | Carbon | Carbon | Carbon | Carbon | — |
| Weight | 1.69 kg | 6.67 kg | 8.27 kg | 7.68 kg | 7.26 kg | 1.5 kg | 1.45 kg | 7.25 kg |
| Sizes | 54, 56, 58, 61, 49, 52, 44 | — | 54, 56, 58, 61, 49, 52, 44 | 54, 56, 58, 61, 49, 52, 44 | 54, 56, 58, 61, 49, 52, 44 | 54, 56, 58, 61, 49, 52, 44 | 54, 56, 58, 61, 49, 52, 44 | 54, 56, 58, 61, 49, 52, 44 |
| Colors | Satin Carbon, Red Pearl / Metallic White Silver | Gloss Premium Fjord Metallic | Gloss Black | Satin Carbon | Gloss Deep Lake Metallic / Green Pearl Over Seafoam | Demi Dreaming Ltd | Yoon Hyup | Gloss Red Sky |
| Gears | — | 24 | — | 24 | 24 | — | — | 24 |
| Frame | ||||||||
| Frame | Threaded Tarmac SL8 FACT 10r , Rider First Engineered™, Win Tunnel Engineered, Clean Routing, BB | S-Works Tarmac SL8 FACT 12r | FACT Tarmac SL7 9r | FACT Tarmac SL8 10r , Rider First Engineered™, Win Tunnel Engineered, Clean Routing | FACT Tarmac SL8 10r , Rider First Engineered™, Win Tunnel Engineered, Clean Routing | Threaded S-Works Tarmac SL8 FACT 12r , Rider First Engineered™, Win Tunnel Engineered, Clean Routing, Ceramic Speed SLT Headset bearings, BB, thru-axle, flat-mount disc | Threaded S-Works Tarmac SL8 FACT 12r , Rider First Engineered™, Win Tunnel Engineered, Clean Routing, BB, thru-axle, flat-mount disc | Demo Demo |
| Fork | FACT 10r Carbon, flat-mount disc | S-Works FACT 12r Carbon | FACT Carbon | FACT 10r Carbon | FACT 10r Carbon | S-Works FACT 12r Carbon, thru-axle, flat-mount disc | S-Works FACT 12r Carbon, thru-axle, flat-mount disc | FACT 10r Carbon |
| Cockpit | ||||||||
| Stem | Integrated Tarmac stem, 6-degree | Integrated Roval Rapide Cockpit, Bar/Stem | Integrated Tarmac stem | Integrated Tarmac stem | Integrated Tarmac stem | — | — | Integrated in Roval Rapide Cockpit |
| Handlebar | — | Integrated Roval Rapide Cockpit, Bar/Stem | Specialized Shallow Drop | Specialized Shallow Drop, 6061 | Specialized Expert Shallow Drop | — | — | Roval Rapide Cockpit |
| Grips | — | Supacaz Super Sticky Kush | — | Supacaz Super Sticky Kush | Supacaz Super Sticky Kush | — | — | Supacaz Super Sticky Kush |
| Seat | ||||||||
| Seatpost | S-Works Tarmac SL8 seat post, FACT , 15mm offset | S-Works Tarmac SL8 Carbon seat post | S-Works 2021 Tarmac Carbon seat post | S-Works Tarmac SL8 seat post, FACT , 15mm offset | S-Works Tarmac SL8 Carbon seat post | S-Works Tarmac SL8 seat post, FACT , 15mm offset | S-Works Tarmac SL8 seat post, FACT , 15mm offset | S-Works Tarmac SL8 seat post, FACT , 15mm offset |
| Seatpost Clamp | Integrated Tarmac wedge | Integrated Tarmac wedge | Integrated Tarmac wedge | Integrated Tarmac wedge | Integrated Tarmac wedge | Integrated Tarmac wedge | Integrated Tarmac wedge | Integrated Tarmac wedge |
| Saddle | — | S-Works Power with Mirror | Power Body Geometry Sport, steel rails | Power Body Geometry Sport, steel rails | Power Body Geometry Expert | — | — | Power Body Geometry Pro Mirror |
| Drivetrain | ||||||||
| Bottom bracket | Threaded 68mm bottom bracket | Shimano Dura-Ace, BB-R9100 | Threaded Shimano BB | Threaded Shimano BB | SRAM DUB BSA | Threaded Threaded BB | Threaded Threaded BB | SRAM DUB |
| Front Derailleur | — | Shimano Dura-Ace R950 | Shimano 105, Braze-on | Shimano 105 R7170, braze-on | SRAM NEW Force AXS E1 | — | — | SRAM Force AXS E1 |
| Front Shifter | — | Shimano Dura-Ace R9270 | Shimano 105 | Shimano 105 Di2 R7170, 12-speed | SRAM NEW Force AXS E1 HRD | — | — | SRAM Force AXS E1 HRD |
| Front Chainring | — | Shimano Dura-Ace R900 | — | Shimano 105 R7100 | SRAM NEW Force E1 | — | — | Shimano Ultegra R81000 |
| Back Derailleur | — | Shimano Dura-Ace R9250 | Shimano 105 R7100, -Speed | Shimano 105 Di2 7150 | SRAM NEW Force AXS E1 | — | — | Shimano Ultegra Di2 R8150, -speed |
| Back Shifter | — | Shimano Dura-Ace R9270 | Shimano 105 | Shimano 105 Di2 R7170, 12-speed | SRAM NEW Force AXS E1 HRD | — | — | SRAM Force AXS E1 HRD |
| Cassette | — | SRAM Red XG-90 | Shimano 105, 12-speed | Shimano 105, 12-speed | SRAM NEW Force XG-70 | — | — | SRAM Force XG-70 E1 |
| Chain | — | Shimano XTR M9100 | Shimano SLX, M7100, -speed | Shimano SLX, M7100, -speed | SRAM NEW Force E1 | — | — | Shimano XT M8100, -speed |
| Crank | — | Shimano Dura-Ace R9200 with 4iiii Precision Pro dual-sided powermeter | Shimano 105, 12-speed | Shimano 105 R7100 | SRAM NEW Force E1 | — | — | Power SRAM Force E1 Meter |
| Wheels | ||||||||
| Front Wheel | — | Roval Rapide CLX III (700c, 12x100mm) | Specialized DT Swiss R470 rim, full sealed bearing thru axle hub (12x100mm) | Specialized DT Swiss R470 rim, full sealed bearing thru axle hub (12x100mm) | Roval C38 (12x100mm) | — | — | Roval Rapide CL III (700c, 12x100 mm) |
| Front Tire | — | S-Works Turbo TLR Race Tire (700c, 28c) | Turbo Pro (700, 26mm) | S-Works Turbo, 120 TPI, folding bead, BlackBelt protection (700x26mm, 26mm) | S-Works Turbo, 120 TPI, BlackBelt protection (700x26mm, 26mm) | — | — | S-Works Turbo TLR Race Tire (700c, 28c) |
| Back Wheel | — | Roval Rapide CLX III (700c, 12x142mm) | Specialized DT Swiss R470 rim, full sealed bearing thru axle hub (12x142mm) | Specialized DT Swiss R470 rim, full sealed bearing thru axle hub (12x142mm) | Roval C38 (12x142mm) | — | — | Roval Rapide CL III (700c, 12x142 mm) |
| Back Tire | — | S-Works Turbo TLR Race Tire (700c, 28c) | Turbo Pro (700, 26mm) | S-Works Turbo, 120 TPI, folding bead, BlackBelt protection (700x26mm, 26mm) | S-Works Turbo, 120 TPI, BlackBelt protection (700x26mm, 26mm) | — | — | S-Works Turbo TLR Race Tire (700c, 28c) |
| Brakes | ||||||||
| Front Brake | — | Shimano Dura-Ace BR-R9270 hydraulic disc | Shimano 105, Hydraulic disc | Shimano 105 Hydraulic Brake | SRAM NEW Force AXS E1, hydraulic disc | — | — | Shimano Ultegra BR-R8170 hydraulic disc |
| Back Brake | — | Shimano Dura-Ace BR-R9270 hydraulic disc | Shimano 105, Hydraulic disc | Shimano 105 Hydraulic Brake | SRAM NEW Force AXS E1, hydraulic disc | — | — | Shimano Ultegra BR-R8170 hydraulic disc |
| Front Disc | — | — | — | — | SRAM Force AXS E1 Rotor | — | — | SRAM Force AXS E1 |
| Back Disc | — | — | — | — | SRAM Force AXS E1 Rotor | — | — | SRAM Force AXS E1 |
Replacement Parts
Find compatible wear items and replacement parts for your bike. Components are organized by category to help you maintain and upgrade your ride.
Drivetrain
Maintain optimal power transfer with the correct drivetrain components for your Tarmac SL8 Frameset. We recommend adhering to manufacturer standards for best shifting performance, though compatible third-party options exist for upgrades or budget repairs.
No resources available yet
Bottom bracket
Recommended OEM Spec:
Threaded 68mm bottom bracket
Suspension & Bearings
Maintain your Tarmac SL8 Frameset's suspension performance with the correct bearings and service parts. Regular maintenance ensures consistent handling and extends component life.
No resources available yet
Fork
Recommended OEM Spec:
FACT 10r Carbon, flat-mount disc
Cockpit
Customize your Tarmac SL8 Frameset's cockpit with compatible handlebars, stems, and grips. These contact points affect comfort, control, and overall riding experience.
No resources available yet
Seatpost
Recommended OEM Spec:
S-Works Tarmac SL8 seat post, FACT , 15mm offset
Seatpost Clamp
Recommended OEM Spec:
Integrated Tarmac wedge
Stem
Recommended OEM Spec:
Integrated Tarmac stem, 6-degree
Accessories
Compatible accessories matched to your bike's specifications. Find the perfect upgrades and add-ons.
No compatible accessories found
Accessories are matched based on bike specifications
Geometry
Frame geometry specifications by size. Compare reach, stack, and other key measurements across available frame sizes.
| Measurement | 44 | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|---|
| Reach | 366mm | 375mm | 380mm | 384mm | 395mm | 402mm | 408mm |
| Stack | 501mm | 514mm | 527mm | 544mm | 565mm | 591mm | 612mm |
| Stack-to-Reach Ratio | — | — | — | — | — | — | — |
| Top Tube Length | — | — | — | — | — | — | — |
| Head Tube Angle | 70.5° | 71.8° | 72.5° | 73° | 73.5° | 73.5° | 74° |
| Seat Tube Angle (Effective) | 75.5° | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
| Head Tube Length | 99mm | 109mm | 120mm | 137mm | 157mm | 184mm | 204mm |
| Seat Tube Length | 433mm | 445mm | 456mm | 473mm | 494mm | 515mm | 545mm |
| Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
| Wheelbase | 970mm | 973mm | 975mm | 978mm | 991mm | 1006mm | 1013mm |
| BB Drop | 74mm | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
| Standover Height | 723mm | 735mm | 746mm | 768mm | 786mm | 808mm | 834mm |
| Front Center | — | — | — | — | — | — | — |
