Santa Cruz
Megatower R
2026Mountain - Enduro
Megatower R Data
- MSRP
- EUR 5399.00
- Suspension
- Fully, Full Suspension
- Travel
- Front: 170mm, Rear: 165mm
- Gears
- 12
- Weight
- 15.68 kg
- Sizes
- S, M, L, Xl, Xxl
- Colors
- Gloss Carbon, Gloss Purple
- EAN
- 58-24263-106-2-821-394001
Components
Complete component specification list for this variant.
Drivetrain
Rear Derailleur
SRAM NX EAGLE
- Gears
- 12
Chain
SRAM NX Eagle
- Gears
- 12
Cassette
SRAM PG30
- Number of sprockets
- 12
- Range
- 11-50t
Crank
Descendant SRAM Eagle 148 DUB
Chainring
Descendant SRAM Eagle
- Ring 1
- 32 Teeth
Bottom Bracket
Threaded SRAM DUB 68/73mm BB
- Standard
- 73mm Threaded
Rear Shifter
SRAM NX Eagle
Cockpit
Grips
Santa Cruz Bicycles House Grips
Stem
e.13 Base
Handlebar
e.13 TRS Base
Seat
Seatpost Clamp
Santa Cruz Seat Clamp
Seatpost
SDG Tellis Dropper
- Diameter
- 31.6 mm
- Dropper post
- 1
Saddle
WTB Silverado
Brakes
Front
Front Disc
Centerline Avid
- Diameter
- 200 mm
Front Brake
SRAM G2 RE
Rear
Rear Disc
Centerline Avid
- Diameter
- 200 mm
Rear Brake
SRAM G2 RE
Wheels
Front
Front Tire
Maxxis Assegai 3C, MaxxGrip, EXO (29", 2.5")
- Size
- 29"
- Width
- 2.5"
Front Wheel
Face AR Offset Rim / SRAM MTH 716 Hub (29", 15x110 mm)
- Size
- 29"
- Axle Dimension
- 15x110 mm
- Rotor mount
- 6-Bolt
- Inner width
- 30 mm
Rear
Rear Tire
Maxxis Minion DHR II 3C MaxxTerra, EXO (29", 2.4"WT)
- Size
- 29"
- Width
- 2.4"WT
Rear Wheel
Face AR Offset Rim / SRAM MTH 746 Hub (29", 12x148 mm)
- Size
- 29"
- Axle Dimension
- 12x148 mm
- Rotor mount
- 6-Bolt
- Inner width
- 30 mm
Frame
Rear Shock
RockShox Super Deluxe Select, 230x62.5
- Travel
- 165 mm
Fork
RockShox Zeb Base
- Travel
- 170 mm
- Front Axle Dimension
- 15x110 mm
- Offset
- 44 mm
Frame
Megatower Carbon C
Accessories
Chainguard
e.13 TRS Race SL, ISCG05
Comparison
Compare specifications and components across all variants of this model. Toggle years to customize your comparison.
Model Year:
| Current Megatower R 2026 CurrentCurrentSanta Cruz Megatower R 2026 |  Megatower 90 2026 |  Megatower Frame 2024 2026 |  Megatower GX AXS 2024 2026 |  Megatower GX AXS Coil 2024 2026 |  Megatower GX AXS RSV 2024 2026 |  Megatower GX AXS RSV Coil 2024 2026 |  Megatower S 2026 |  Megatower X0 AXS 2024 2026 |  Megatower X0 AXS Coil 2024 2026 |  Megatower X0 AXS RSV 2024 2026 |  Megatower X0 AXS RSV Coil 2024 2026 |  Megatower XX AXS RSV 2024 2026 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Specifications | |||||||||||||
| MSRP | EUR 5399.00 | EUR 6599.00 | EUR 3899.00 | EUR 7199.00 | EUR 7199.00 | EUR 8299.00 | EUR 8299.00 | EUR 5999.00 | EUR 9299.00 | EUR 9299.00 | EUR 10499.00 | EUR 10499.00 | EUR 11999.00 |
| Suspension | Fully, Full Suspension | Fully, Hardtail | Fully | Fully, Full Suspension | Fully, Full Suspension | Fully, Full Suspension | Fully | Fully | Fully, Full Suspension | Fully, Full Suspension | Fully, Full Suspension | Fully, Full Suspension | Fully, Full Suspension |
| Travel | Front: 170mm, Rear: 165mm | Front: 170mm | Rear: 165mm | Front: 170mm, Rear: 165mm | Front: 170mm, Rear: 165mm | Front: 170mm, Rear: 165mm | Rear: 165mm | Rear: 165mm | Front: 170mm, Rear: 165mm | Front: 170mm, Rear: 165mm | Front: 170mm, Rear: 165mm | Front: 170mm, Rear: 165mm | Front: 170mm, Rear: 165mm |
| Gears | 12 | 12 | — | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| Weight | 15.68 kg | 16.36 kg | 3250 kg | 15.24 kg | 16150 kg | 15.19 kg | 16.1 kg | 15.46 kg | 15.27 kg | 16000 kg | 15.23 kg | 15960 kg | 15050 kg |
| Sizes | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl | S, M, L, Xl, Xxl |
| Colors | Gloss Carbon, Gloss Purple | Gloss Silver, Matte Olive Drab | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple | Gloss Carbon, Gloss Purple |
| EAN | 58-24263-106-2-821-394001 | 58-26263-455-2-900-212501 | 68-24264-2-821-4499 | 58-24263-163-2-821-434201 | 58-24263-163-2-821-414201 | 58-24263-163-2-821-434202 | 58-24263-163-2-821-414202 | 58-24263-109-2-821-404101 | 58-24264-185-2-821-444301 | 58-24264-185-2-821-424301 | 58-24264-185-2-821-444302 | 58-24264-185-2-821-424302 | 58-24264-188-2-821-444302 |
| Frame | — | Carbon C | Carbon CC | — | Carbon fiber | — | — | — | Carbon | Carbon CC | Carbon | Carbon | Carbon |
| Wheels | |||||||||||||
| Front Tire | Maxxis Assegai 3C, MaxxGrip, EXO (29", 2.5") | Maxxis Assegai 3C MaxxGrip, EXO (29", 2.5") | — | Maxxis Assegai 3C MaxxGrip, EXO+, TR (29, 2.5") | Maxxis Assegai 3C MaxxGrip, Double Down, TR (29", 2.5") | Maxxis Assegai 3C MaxxGrip EXO TR (29, 2.5) | Maxxis Assegai | Maxxis Assegai 3C MaxxGrip EXO (29, 2.5) | Maxxis Assegai 3C MaxxGrip EXO (29, 2.5) | Maxxis Assegai 3C MaxxGrip Double Down (29, 2.5") | Maxxis Assegai, 3C, MaxxGrip, EXO (29, 2.5") | Maxxis Assegai 3C MaxxGrip Double Down (29", 2.5") | Maxxis Assegai 3C MaxxGrip EXO (29, 2.5") |
| Back Tire | Maxxis Minion DHR II 3C MaxxTerra, EXO (29", 2.4"WT) | Maxxis Minion DHR II 3C MaxxTerra, Double Down (29", 2.4") | — | Maxxis Minion DHR II WT, 3C MaxxTerra, EXO+, TR (29, 2.4") | Maxxis Minion DHR II 3C MaxxGrip, Double Down, TR (29", 2.4") | Maxxis Minion DHR II 3C MaxxTerra EXO TR (29, 2.4) | Maxxis Minion DHR II | Maxxis Minion DHR II 3C MaxxTerra EXO (29, 2.4) | Maxxis Minion DHR II 3C MaxxTerra EXO (29, 2.4) | Maxxis Minion DHR II 3C MaxxGrip Double Down (29, 2.4") | Maxxis Minion DHR II, 3C MaxxTerra, EXO (29, 2.4") | Maxxis Minion DHR II 3C MaxxGrip Double Down (29", 2.4") | Maxxis Minion DHR II 3C MaxxTerra EXO (29, 2.4") |
| Front Wheel | Face AR Offset Rim / SRAM MTH 716 Hub (29", 15x110 mm) | DT Swiss 370 / Reserve |TR AL (29", 15x110 mm) | — | Face ARC Offset " / i9 1/1 (29, 15x110 mm) | Face ARC Offset 30 " / i9 1/1 (29, 15x110) | Reserve |HD " / i9 1/1 (29, 15x110) | DT Swiss Reserve 30|HD " with 370 Hub (29, 15x110) | DT Swiss RaceFace AR Offset Rim / 370 Hub (29, 15x110 mm) | Industry RaceFace ARC Offset " / Nine 1/1 (29, 15x110 mm) | Industry Nine 1/1, 15x110, Torque Cap, , 28h with RaceFace ARC Offset " (29, 15x110 mm) | Industry Reserve |HD " with Nine 1/1 or DT Swiss 350 (29, 15x110 mm) | Industry Reserve 30|HD Rim, Nine 1/1 Hub (29", 15x110 mm) | Industry Reserve |HD " on Nine Hydra Hub (29, 15x110 mm) |
| Back Wheel | Face AR Offset Rim / SRAM MTH 746 Hub (29", 12x148 mm) | DT Swiss 370 / Reserve |HD AL (29", 12x148 mm) | — | Face ARC Offset " / i9 1/1 (29, 12x148 mm) | Face ARC Offset 30 " / i9 1/1 (29, 12x148) | Reserve |HD " / i9 1/1 (29, 12x148) | DT Swiss Reserve 30|HD " with 370 Hub (29, 12x148) | DT Swiss RaceFace AR Offset Rim / 370 Hub (29, 12x148 mm) | Industry RaceFace ARC Offset " / Nine 1/1 (29, 12x148 mm) | Industry Nine 1/1, 12x148, XD, , 28h with RaceFace ARC Offset " (29, 12x148 mm) | Industry Reserve 30|HD " with Nine 1/1 or DT Swiss 350 (29, 12x148 mm) | Industry RaceFace ARC Offset 30 Rim, Nine 1/1 Hub (29", 12x148 mm) | Industry Reserve |HD " on Nine Hydra Hub (29, 12x148 mm) |
| Brakes | |||||||||||||
| Front Brake | SRAM G2 RE | SRAM Maven Base | — | SRAM Code RS | SRAM Code RS | SRAM Code RS | SRAM Code Bronze Stealth | SRAM Code R | SRAM Code Silver Stealth | SRAM Code Silver Stealth | SRAM Code Silver Stealth | SRAM Code Silver Stealth | SRAM Code Ultimate Stealth |
| Back Brake | SRAM G2 RE | SRAM Maven Base | — | SRAM Code RS | SRAM Code RS | SRAM Code RS | SRAM Code Bronze Stealth | SRAM Code R | SRAM Code Silver Stealth | SRAM Code Silver Stealth | SRAM Code Silver Stealth | SRAM Code Silver Stealth | SRAM Code Ultimate Stealth |
| Front Disc | Centerline Avid | SRAM HS2 | — | Centerline Avid | Centerline Avid | Centerline Avid | SRAM HS2 | Centerline Avid | SRAM HS2 | SRAM HS2 | SRAM HS2 | SRAM HS2 | SRAM HS2 |
| Back Disc | Centerline Avid | SRAM HS2 | Compatible mm PM | Centerline Avid | Centerline Avid | Centerline Avid | SRAM HS2 | Centerline Avid | SRAM HS2 | SRAM HS2 | SRAM HS2 | SRAM HS2 | SRAM HS2 |
| Frame | |||||||||||||
| Frame | Megatower Carbon C | 29" VPP™ | Megatower Megatower CC | Megatower Carbon C | Santa Cruz Megatower Carbon C | Megatower Carbon C | Megatower Carbon C | Megatower Carbon C | Megatower Carbon CC | Megatower Carbon CC | Megatower Carbon CC | Megatower Carbon CC | Santa Cruz Megatower CC |
| Rear Shock | RockShox Super Deluxe Select, 230x62.5 | FOX Float X Performance | FACT FOX Float X2 ory, 230x62.5 | RockShox Super Deluxe Select | RockShox Super Deluxe Select+ Coil | RockShox Super Deluxe Select | RockShox Super Deluxe Select+ Coil | RockShox Super Deluxe Select+ | FACT FOX Float X2 ory | RockShox Super Deluxe Ultimate Coil | FACT FOX Float X2 ory | RockShox Super Deluxe Ultimate Coil | FACT FOX Float X2 ory |
| Fork | RockShox Zeb Base | Performance FOX 38 Float , Grip | — | Performance FOX 38 Float Elite | Performance FOX 38 Float Elite | Performance FOX 38 Float Elite | RockShox Zeb Select+ | FOX 38 Float Performance | RockShox Zeb Ultimate | RockShox Zeb Ultimate | RockShox Zeb Ultimate | RockShox Zeb Ultimate | RockShox Zeb Ultimate |
| Drivetrain | |||||||||||||
| Back Derailleur | SRAM NX EAGLE | SRAM 90 Eagle T-Type | — | SRAM GX AXS Eagle, spd | SRAM GX AXS Eagle, spd | SRAM GX AXS Eagle, spd | SRAM GX Eagle AXS T-Type | SRAM GX Eagle | SRAM X0 Eagle AXS T-Type | SRAM X0 Eagle AXS T-Type | SRAM X0 Eagle AXS T-Type | SRAM X0 Eagle AXS T-Type | SRAM XX Eagle AXS T-Type |
| Back Shifter | SRAM NX Eagle | SRAM 90 Eagle T-Type | — | CONTROL GX AXS ler | CONTROL GX AXS ler | CONTROL GX AXS ler | Bridge SRAM AXS Pod | SRAM GX Eagle | Bridge SRAM AXS Pod | Bridge SRAM AXS Pod | Bridge SRAM AXS Pod | Bridge SRAM AXS Pod | Bridge SRAM AXS Pod Ultimate |
| Cassette | SRAM PG30 | SRAM XS 75 Eagle T-Type | — | SRAM XG75 Eagle | SRAM XG75 Eagle | SRAM XG75 Eagle | SRAM GX Eagle T-Type | SRAM XG75 Eagle | SRAM X0 Eagle T-Type | SRAM X0 Eagle T-Type | SRAM X0 Eagle T-Type | SRAM X0 Eagle T-Type | SRAM XX Eagle T-Type |
| Chain | SRAM NX Eagle | SRAM GX Eagle T-Type, Flattop | — | SRAM GX Eagle | SRAM GX Eagle | SRAM GX Eagle | SRAM GX Eagle T-Type, Flattop | SRAM GX Eagle | SRAM X0 Eagle T-Type Flattop | SRAM X0 Eagle T-Type, Flattop | SRAM X0 Eagle T-Type, Flattop | SRAM X0 Eagle T-Type, Flattop | SRAM XX Eagle T-Type, Flattop |
| Crank | Descendant SRAM Eagle 148 DUB | SRAM 90 Eagle DUB T-Type Crankset | — | SRAM GX Eagle 148 DUB | SRAM GX Eagle 148 DUB | SRAM GX Eagle 148 DUB | SRAM GX Eagle DUB T-Type Crankset | SRAM GX Eagle 148 DUB | SRAM X0 Eagle DUB T-Type Crankset | SRAM X0 Eagle DUB T-Type Crankset | SRAM X0 Eagle DUB T-Type Crankset | SRAM X0 Eagle DUB T-Type Crankset | SRAM XX Eagle DUB T-Type Crankset |
| Front Chainring | Descendant SRAM Eagle | SRAM 90 Eagle T-Type | — | SRAM GX Eagle | SRAM GX Eagle Ring | SRAM GX Eagle | SRAM GX Eagle T-Type | SRAM GX Eagle | SRAM X0 Eagle T-Type | SRAM X0 Eagle T-Type | SRAM X0 Eagle T-Type | SRAM X0 Eagle T-Type | SRAM XX Eagle T-Type |
| Bottom bracket | Threaded SRAM DUB 68/73mm BB | SRAM DUB 73mm MTB Wide BB | 73mm Threaded | Threaded SRAM DUB 68/73mm BB | Threaded SRAM DUB 68/73mm BB | Threaded SRAM DUB 68/73mm BB | SRAM DUB 73mm MTB Wide BB | Threaded SRAM DUB 68/73mm BB | SRAM DUB 73mm MTB Wide BB | SRAM DUB 73mm MTB Wide BB | SRAM DUB 73mm MTB Wide BB | SRAM DUB 73mm MTB Wide BB | SRAM DUB 73mm MTB Wide BB |
| Battery | — | — | — | — | SRAM eTap Powerpack | — | — | — | Power SRAM eTap pack 1 Battery | — | — | — | — |
| Cockpit | |||||||||||||
| Stem | e.13 Base | OneUp Enduro Stem | — | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Burgtec Enduro MK3 | Industry Nine A |
| Handlebar | e.13 TRS Base | OneUp Bar | — | Santa Cruz 35 Carbon Bar | Santa Cruz 35 Carbon Bar | Santa Cruz 35 Carbon Bar | Santa Cruz Carbon | Burgtec RideWide | Santa Cruz 35 Carbon Bar | Santa Cruz 35 Carbon Bar | Santa Cruz 35 Carbon Bar | Santa Cruz 35 Bar | Santa Cruz 35 Carbon Bar |
| Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | — | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips | Santa Cruz Bicycles House Grips |
| Seat | |||||||||||||
| Saddle | WTB Silverado | SDG Bel-Air V3 Lux-Alloy | — | WTB Silverado Medium CroMo | WTB Silverado Medium CroMo | WTB Silverado Medium CroMo | WTB Silverado Medium, CroMo | WTB Silverado | WTB Silverado Medium, Ti | WTB Silverado Medium, Ti | WTB Silverado Medium, Ti | WTB Silverado Medium, Ti | WTB Silverado Medium, Ti |
| Seatpost | SDG Tellis Dropper | OneUp Dropper Post | mm Diameter | RockShox Reverb Stealth | RockShox Reverb Stealth | RockShox Reverb Stealth | OneUp V2 Dropper Post | OneUp V2 Dropper Post | OneUp V2 Dropper Post | OneUp V2 Dropper Post | OneUp V2 Dropper Post | OneUp V2 Dropper Post | OneUp V2 Dropper Post |
| Seatpost Clamp | Santa Cruz Seat Clamp | — | 36.4mm Clamp | Santa Cruz Santa Cruz | Santa Cruz Seat Clamp | Santa Cruz Seat Clamp | — | Santa Cruz Bicycles Seat Clamp | Santa Cruz Bicycles Seat Clamp | Santa Cruz Seat Clamp | Santa Cruz Bicycles Seat Clamp | Santa Cruz Seat Clamp | Santa Cruz Seat Clamp |
| Accessories | |||||||||||||
| Chainguard | e.13 TRS Race SL, ISCG05 | OneUp Bash Guide | — | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide | OneUp Bash Guide |
| Charger | — | — | — | Power SRAM eTap pack 1 Battery & Charger | Power SRAM eTap pack 1 Battery Charger | Power SRAM eTap pack 1 Battery Charger | Power SRAM eTap pack 1 Battery & Charger | — | — | Power SRAM eTap pack 1 Battery Charger | Power SRAM eTap pack 1 Battery Charger | Power SRAM eTap pack 1 Battery & Charger | Power SRAM eTap pack 1 Battery & Charger |
Replacement Parts
Find compatible wear items and replacement parts for your bike. Components are organized by category to help you maintain and upgrade your ride.
Drivetrain
Maintain optimal power transfer with the correct drivetrain components for your Megatower R. We recommend adhering to manufacturer standards for best shifting performance, though compatible third-party options exist for upgrades or budget repairs.
No resources available yet
Back Derailleur
Recommended OEM Spec:
SRAM NX EAGLE
Chain
Recommended OEM Spec:
SRAM NX Eagle
Cassette
Recommended OEM Spec:
SRAM PG30
Front Chainring
Recommended OEM Spec:
Descendant SRAM Eagle
Bottom bracket
Recommended OEM Spec:
Threaded SRAM DUB 68/73mm BB
Chainguard
Recommended OEM Spec:
e.13 TRS Race SL, ISCG05
Brakes
Ensure safe stopping power with the right brake components for your Megatower R. OEM parts guarantee compatibility, while aftermarket alternatives can offer performance upgrades or cost savings.
No resources available yet
Front Disc
Recommended OEM Spec:
Centerline Avid
Back Disc
Recommended OEM Spec:
Centerline Avid
Front Brake
Recommended OEM Spec:
SRAM G2 RE
Back Brake
Recommended OEM Spec:
SRAM G2 RE
Tires & Tubes
Keep your Megatower R rolling smoothly with properly matched tires and tubes. The recommended specs ensure optimal grip, puncture protection, and ride quality for your specific setup.
No resources available yet
Front Tire
Recommended OEM Spec:
Maxxis Assegai 3C, MaxxGrip, EXO (29", 2.5")
Back Tire
Recommended OEM Spec:
Maxxis Minion DHR II 3C MaxxTerra, EXO (29", 2.4"WT)
Suspension & Bearings
Maintain your Megatower R's suspension performance with the correct bearings and service parts. Regular maintenance ensures consistent handling and extends component life.
No resources available yet
Rear Shock
Recommended OEM Spec:
RockShox Super Deluxe Select, 230x62.5
Fork
Recommended OEM Spec:
RockShox Zeb Base
Cockpit
Customize your Megatower R's cockpit with compatible handlebars, stems, and grips. These contact points affect comfort, control, and overall riding experience.
No resources available yet
Grips
Recommended OEM Spec:
Santa Cruz Bicycles House Grips
Stem
Recommended OEM Spec:
e.13 Base
Handlebar
Recommended OEM Spec:
e.13 TRS Base
Seatpost Clamp
Recommended OEM Spec:
Santa Cruz Seat Clamp
Seatpost
Recommended OEM Spec:
SDG Tellis Dropper
Saddle
Recommended OEM Spec:
WTB Silverado
Wear Items
Replace high-wear items on your Megatower R regularly to maintain performance and safety. These components see frequent use and benefit from periodic replacement.
No resources available yet
Grips
Recommended OEM Spec:
Santa Cruz Bicycles House Grips
Saddle
Recommended OEM Spec:
WTB Silverado
Accessories
Compatible accessories matched to your bike's specifications. Find the perfect upgrades and add-ons.
No compatible accessories found
Accessories are matched based on bike specifications
Geometry
Frame geometry specifications by size. Compare reach, stack, and other key measurements across available frame sizes.
| Measurement | L | M | S | XL | XXL |
|---|---|---|---|---|---|
| Reach | 472mm | 452mm | 427mm | 492mm | 517mm |
| Stack | 640mm | 627mm | 618mm | 658mm | 672mm |
| Stack-to-Reach Ratio | — | — | — | — | — |
| Top Tube Length | 613mm | 595mm | 570mm | 638mm | 667mm |
| Head Tube Angle | 63.5° | 63.5° | 63.5° | 63.5° | 63.5° |
| Seat Tube Angle (Effective) | 77.5° | 77.2° | 77° | 77.5° | 77.5° |
| Head Tube Length | 115mm | 100mm | 90mm | 135mm | 150mm |
| Seat Tube Length | 430mm | 405mm | 380mm | 460mm | 500mm |
| Chainstay Length | 441mm | 438mm | 437mm | 444mm | 448mm |
| Wheelbase | 1266mm | 1237mm | 1206mm | 1298mm | 1334mm |
| BB Drop | 30mm | 30mm | 30mm | 30mm | 30mm |
| Standover Height | 718mm | 712mm | 705mm | 717mm | 720mm |
| Front Center | 826mm | 799mm | 770mm | 855mm | 886mm |
