Santa Cruz
Hightower XX AXS RSV 2024
2026Mountain - All-Mountain
Hightower XX AXS RSV 2024 Data
- MSRP
- EUR 11499.00
- Frame
- Carbon CC
- Suspension
- Fully, Full Suspension
- Travel
- Front: 150mm, Rear: 145mm
- Gears
- 12
- Weight
- 13.79 kg
- Sizes
- S, M, L, Xl, Xxl
- Colors
- Gloss Ocean Blue, Matte Cardinal Red
- EAN
- 58-24269-188-2-794-323002
Looking for replacement tires?
View verified compatible tires for the 2026 Hightower XX AXS RSV 2024.
Components
Complete component specification list for this variant.
Drivetrain
Bottom Bracket
SRAM DUB 73mm MTB Wide BB
- Standard
- 73mm Threaded
Cassette
SRAM XX Eagle T-Type
- Number of sprockets
- 12
- Range
- 10-52t
Chain
SRAM XX Eagle T-Type, Flattop
- Gears
- 12
Rear Derailleur
SRAM XX Eagle AXS T-Type
- Gears
- 12
Rear Shifter
Bridge SRAM AXS Pod Ultimate
Crank
SRAM XX Eagle DUB T-Type Crankset
Chainring
SRAM XX Eagle T-Type
- Ring 1
- 32 Teeth
Battery
SRAM AXS Battery
Seat
Saddle
WTB Silverado Medium, Ti
Seatpost
OneUp V2 Dropper Post
- Diameter
- 31.6 mm
- Dropper post
- 1
Seatpost Clamp
Santa Cruz Seat Collar
- Weight
- 36.4 g
Accessories
Charger
Power SRAM eTap pack 1 Battery & Charger
Cockpit
Grips
Santa Cruz Bicycles House Grips
Stem
Industry Nine A
- Length
- 40 mm
- Clamping diameter
- 35 mm
Handlebar
Santa Cruz 35 Carbon Bar
Brakes
Front
Front Brake
SRAM Code Ultimate Stealth
Front Disc
SRAM HS2
Rear
Rear Brake
SRAM Code Ultimate Stealth
Rear Disc
SRAM HS2
Wheels
Front
Front Wheel
Industry Reserve |HD " with Nine Hydra Hub (29, 15x110 mm)
- Size
- 29
- Axle Dimension
- 15x110 mm
- Rotor mount
- 6-Bolt
- Inner width
- 30 mm
- Material
- Carbon
- Position
- front
Front Tire
Maxxis Minion DHR II, 3C MaxxGrip, EXO (29, 2.4)
- Size
- 29
- Width
- 2.4
Rear
Rear Wheel
Industry Reserve |HD " with Nine Hydra Hub (29, 12x148 mm)
- Size
- 29
- Axle Dimension
- 12x148 mm
- Rotor mount
- 6-Bolt
- Inner width
- 30 mm
- Material
- Carbon
- Position
- back
Rear Tire
Maxxis Minion DHR II, 3C MaxxTerra, EXO (29, 2.4)
- Size
- 29
- Width
- 2.4
Frame
Frame
Santa Cruz Hightower
- Rear Axle Dimension
- 12x148 mm
- Tyre clearance
- 2.5 65
- Material
- Carbon CC
Rear Shock
RockShox Super Deluxe Ultimate
- Travel
- 145 mm
Fork
RockShox Lyrik Ultimate
- Travel
- 150 mm
- Front Axle Dimension
- 15x110 mm
- Offset
- 44 mm
