BikeDB
Marin

Rift Zone EL1

2025 Electric
Rift Zone EL1 Data
MSRP
USD 5199.00
Frame
Aluminum
Suspension
Fully, Full Suspension
Travel
Front: 150mm, Rear: 140mm
Gears
10
Sizes
S, M, L, Xl
Colors
Blue/Navy
View on Marin

Components

Complete component specification list for this variant.

Wheels

Front
Front Tire
Maxxis Minion DHF (29", 2.5")
Front Tire
Size
29"
Width
2.5"
Front Wheel
Shimano Marin Aluminum Double Wall / Hub (29", 110x15 Kabolt Thru Axle)
Front Wheel
Size
29"
Axle Dimension
110x15 Kabolt Thru Axle
Rotor mount
Centerlock
Inner width
32 mm
Rear
Rear Tire
Maxxis Forekaster (29", 2.4")
Back Tire
Size
29"
Width
2.4"
Rear Wheel
Shimano Marin Aluminum Double Wall / FHTC500 Hub (29", 148x12 Thru Axle)
Back Wheel
Size
29"
Axle Dimension
148x12 Thru Axle
Rotor mount
Centerlock
Inner width
32 mm

Frame

Frame
Series 4 Alloy Lightweight E
Frame
Rear Axle Dimension
12x148 mm
Material
Aluminum
Pedals
Marin MTB Plastic
Pedals
Type
Flat
Rear Shock
Marzocchi Bomber Air Inline, Custom Tune
Rear Shock
Travel
140 mm
Fork
Marzocchi Bomber Z1
Fork
Travel
150 mm
Front Axle Dimension
110x15 mm
Offset
44 mm

Drivetrain

Motor
Performance Bosch Line SX
Motor
Torque
55 Nm
Display
CONTROL Bosch BRC3100 Systems ler
Display
Crank
e*thirteen e*spec Plus
Crank
Length
160
Chainring
e*thirteen e*thirteen
Front Chainring
Ring 1
34 Teeth
Battery
CompactTube Bosch Wh Internal
Battery
Capacity
400 Wh
Range Extender / Battery 2
Bosch Optional PowerMore wh external
Battery 2
Capacity
250 Wh
Rear Derailleur
Shimano CUES RD-U6000 GS
Back Derailleur
Gears
10
Rear Shifter
Shimano CUES SL-U6000-10R
Back Shifter
Cassette
Shimano CS-LG300-
Cassette
Number of sprockets
10
Range
11-48T
Chain
Shimano LG500

Cockpit

Grips
Marin Grizzly Lock-On
Grips
Stem
Forged Marin 3D Alloy
Stem
Length
35 mm
Clamping diameter
35 mm
Handlebar
Marin Mini-Riser
Handlebar
Width
780 mm
Rise
28 mm
Angle
9 °
Material
Aluminum

Seat

Saddle
Marin Speed Concept
Saddle
Seatpost
TranzX YSI34 QL
Seatpost
Diameter
34.9 mm
Dropper post
1

Accessories

Chainguard
e*thirteen e*Spec Chainguide
Chainguard

Brakes

Front
Front Brake
TRP Slate EVO
Front Brake
Front Disc
TRP Slate EVO Rotor
Front Disc
Diameter
203 mm
Rear
Rear Brake
TRP Slate EVO
Back Brake
Rear Disc
TRP Slate EVO Rotor
Back Disc
Diameter
203 mm

Comparison

Compare specifications and components across all variants of this model. Toggle years to customize your comparison.

Model Year:
Current
Rift Zone EL1
2025
Rift Zone 2
2025
Rift Zone EL XR
2025
Rift Zone EL2
2025
Rift Zone XR AXS
2025
Specifications
MSRPUSD 5199.00EUR 2299.00USD 7699.00USD 6499.00EUR 5399.00
FrameAluminumAluminumAluminumAluminumAluminum
SuspensionFully, Full SuspensionFully, Full SuspensionFully, Full SuspensionFully, Full SuspensionFully, Full Suspension
TravelFront: 150mm, Rear: 140mmFront: 140mm, Rear: 130mmFront: 150mm, Rear: 140mmFront: 150mm, Rear: 140mmFront: 150mm, Rear: 130mm
Gears10—1212—
SizesS, M, L, XlS, M, L, XlS, M, L, XlS, M, L, XlS, M, L, Xl
ColorsBlue/NavyGrey/BlueTan/BrownSilverOrange/Yellow
Wheels
Front Wheel
Shimano Marin Aluminum Double Wall / Hub (29", 110x15 Kabolt Thru Axle)
Shimano HF-MT410B Hub / Marin Double Wall Rim (110x15mm)
Double Marin Wall Rim | Formula DCL-3482 Hub (29", 148x12)
Marin Aluminum Double Wall
Double Marin Wall rim, Formula DC-711 hub (29", 110x15mm)
Back Wheel
Shimano Marin Aluminum Double Wall / FHTC500 Hub (29", 148x12 Thru Axle)
Shimano FH-TC500 Hub / Marin Double Wall Rim (148x12mm)
Double Marin Wall Rim | Formula DC-711 Hub (29", 110x15)
Marin Aluminum Double Wall
Double Marin Wall rim, Formula DCL-3482 hub (29", 148x12mm)
Front Tire
Maxxis Minion DHF (29", 2.5")
Vee Tire Snap WCE (2.35")
Maxxis Minion DHF (29", 2.5")
Maxxis Minion DHF (29", 2.5")
Maxxis Assegai
Back Tire
Maxxis Forekaster (29", 2.4")
Vee Tire Snap WCE (2.35")
Maxxis Forekaster (29", 2.4")
Maxxis Forekaster (29", 2.4")
Maxxis Assegai
Brakes
Front Brake
TRP Slate EVO
Tektro HD-M535 Hydraulic Disc
Magura MT7 with HC3 Lever
SRAM Code Bronze
SRAM Code Bronze 4-Piston Hydraulic Disc
Back Brake
TRP Slate EVO
Tektro HD-M535 Hydraulic Disc
Magura MT7 with HC3 Lever
SRAM Code Bronze
SRAM Code Bronze 4-Piston Hydraulic Disc
Front Disc
TRP Slate EVO Rotor
Tektro Tektro
Magura MDR Rotor
SRAM HS2 Rotor
SRAM HSC
Back Disc
TRP Slate EVO Rotor
Tektro Tektro
Magura MDR Rotor
SRAM HS2 Rotor
SRAM HSC
Frame
Frame
Series 4 Alloy Lightweight E
Series 3 6061 Frame
Series 4 Alloy Lightweight E
Series 4 Alloy Lightweight E
Series 3 6061
Rear Shock
Marzocchi Bomber Air Inline, Custom Tune
RockShox Deluxe Select RT
Performance Fox Float X, Elite
Performance Fox Float X, , EVOL Air Spring
RockShox Super Deluxe Select+
Fork
Marzocchi Bomber Z1
Marzocchi Bomber Z2 29"
Performance Fox 36 Elite
Performance Fox 36
RockShox Lyrik Select+
Pedals
Marin MTB Plastic
—
Marin MTB Plastic
Marin MTB Plastic
—
Drivetrain
Motor
Performance Bosch Line SX
—
Performance Bosch Line SX
Performance Bosch Line SX
—
Battery
CompactTube Bosch Wh Internal
—
CompactTube Bosch Internal
Bosch Internal
—
Battery 2
Bosch Optional PowerMore wh external
————
Display
CONTROL Bosch BRC3100 Systems ler
—
CONTROL Bosch BRC3100 Systems ler
CONTROL Bosch BRC3100 Systems ler
—
Back Derailleur
Shimano CUES RD-U6000 GS
Shimano Deore SGS
SRAM GX AXS T-Type
SRAM EAGLE 90
SRAM GX Eagle Lunar
Back Shifter
Shimano CUES SL-U6000-10R
Shimano Deore SL-M6100-R
SRAM AXS Pod Infinity Mount
SRAM EAGLE 90 MMX Mount
SRAM AXS Pod MMX
Front Chainring
e*thirteen e*thirteen
FSA Direct Mount
e*thirteen e*thirteen
e*thirteen e*thirteen
SRAM GX Eagle
Cassette
Shimano CS-LG300-
Sunrace
SRAM CS-XS-75 T-Type
SRAM XG 75 Eagle Cassette
SRAM XG 1275 Eagle
Chain
Shimano LG500
KMC X-12
SRAM GX T-Type
SRAM GX T-Type
SRAM GX Eagle T-Type
Crank
e*thirteen e*spec Plus
FSA Comet, Modular 1x
e*thirteen e*spec Plus
e*thirteen e*spec Plus
SRAM GX Eagle
Bottom bracket—
Sealed External Cartridge Bearing
Integrated with Motor
—
SRAM DUB MTB 73
Cockpit
Stem
Forged Marin 3D Alloy
Forged Marin 3D Alloy
Marin CNC
Marin CNC
Marin CNC
Handlebar
Marin Mini-Riser
Double Marin Mini-Riser, 6061 Butted
Marin Trail
Marin Trail
Marin Trail
Grips
Marin Grizzly Lock-On
Marin Grizzly Lock On
Marin Grizzly Lock-On
Marin Grizzly Lock-On
Marin Grizzly Lock-On
Seat
Saddle
Marin Speed Concept
Marin Speed Concept
Marin Speed Concept
Marin Speed Concept
Marin Speed Concept
Seatpost
TranzX YSI34 QL
X-Fusion Manic, x Composite Remote
PNW Loam Post with Range Lever
TranzX YSP39
PNW Loam Post with Range Lever
Accessories
Chainguard
e*thirteen e*Spec Chainguide
—
e*thirteen e*Spec Chainguide
e*thirteen e*Spec Chainguide
—

Replacement Parts

Find compatible wear items and replacement parts for your bike. Components are organized by category to help you maintain and upgrade your ride.

Drivetrain

Maintain optimal power transfer with the correct drivetrain components for your Rift Zone EL1. We recommend adhering to manufacturer standards for best shifting performance, though compatible third-party options exist for upgrades or budget repairs.

No resources available yet

Front Chainring
Front Chainring
Recommended OEM Spec:
e*thirteen e*thirteen
Back Derailleur
Back Derailleur
Recommended OEM Spec:
Shimano CUES RD-U6000 GS
Cassette
Cassette
Recommended OEM Spec:
Shimano CS-LG300-
Chain
Chain
Recommended OEM Spec:
Shimano LG500
Chainguard
Chainguard
Recommended OEM Spec:
e*thirteen e*Spec Chainguide

Brakes

Ensure safe stopping power with the right brake components for your Rift Zone EL1. OEM parts guarantee compatibility, while aftermarket alternatives can offer performance upgrades or cost savings.

No resources available yet

Front Brake
Front Brake
Recommended OEM Spec:
TRP Slate EVO
Back Brake
Back Brake
Recommended OEM Spec:
TRP Slate EVO
Front Disc
Front Disc
Recommended OEM Spec:
TRP Slate EVO Rotor
Back Disc
Back Disc
Recommended OEM Spec:
TRP Slate EVO Rotor

Tires & Tubes

Keep your Rift Zone EL1 rolling smoothly with properly matched tires and tubes. The recommended specs ensure optimal grip, puncture protection, and ride quality for your specific setup.

No resources available yet

Front Tire
Front Tire
Recommended OEM Spec:
Maxxis Minion DHF (29", 2.5")
Back Tire
Back Tire
Recommended OEM Spec:
Maxxis Forekaster (29", 2.4")

Suspension & Bearings

Maintain your Rift Zone EL1's suspension performance with the correct bearings and service parts. Regular maintenance ensures consistent handling and extends component life.

No resources available yet

Rear Shock
Rear Shock
Recommended OEM Spec:
Marzocchi Bomber Air Inline, Custom Tune
Fork
Fork
Recommended OEM Spec:
Marzocchi Bomber Z1

Cockpit

Customize your Rift Zone EL1's cockpit with compatible handlebars, stems, and grips. These contact points affect comfort, control, and overall riding experience.

No resources available yet

Grips
Grips
Recommended OEM Spec:
Marin Grizzly Lock-On
Stem
Stem
Recommended OEM Spec:
Forged Marin 3D Alloy
Handlebar
Handlebar
Recommended OEM Spec:
Marin Mini-Riser
Saddle
Saddle
Recommended OEM Spec:
Marin Speed Concept
Seatpost
Seatpost
Recommended OEM Spec:
TranzX YSI34 QL

Wear Items

Replace high-wear items on your Rift Zone EL1 regularly to maintain performance and safety. These components see frequent use and benefit from periodic replacement.

No resources available yet

Pedals
Pedals
Recommended OEM Spec:
Marin MTB Plastic
Grips
Grips
Recommended OEM Spec:
Marin Grizzly Lock-On
Saddle
Saddle
Recommended OEM Spec:
Marin Speed Concept

Accessories

Compatible accessories matched to your bike's specifications. Find the perfect upgrades and add-ons.

No compatible accessories found

Accessories are matched based on bike specifications

Geometry

Frame geometry specifications by size. Compare reach, stack, and other key measurements across available frame sizes.

MeasurementLMSXL
Reach485mm465mm445mm515mm
Stack625.1mm614mm607mm634.2mm
Stack-to-Reach Ratio————
Top Tube Length————
Head Tube Angle65°65°65°65°
Seat Tube Angle (Effective)77°77°77°77°
Head Tube Length120mm110mm100mm130mm
Seat Tube Length425mm400mm390mm435mm
Chainstay Length440mm440mm440mm440mm
Wheelbase1246.7mm1222.5mm1198.3mm1281mm
BB Drop32mm32mm32mm32mm
Standover Height709.9mm696mm693.7mm719.9mm
Front Center————
