Marin

Gestalt

2025Road - All-Road
Gestalt Data
MSRP
EUR 1099.00
Frame
6061 Aluminum
Suspension
None, Hardtail
Gears
16
Sizes
54, 56, 58, 52, 50, 60
Colors
Gloss Black, Gloss Blue
View on Marin

Looking for replacement tires?

View verified compatible tires for the 2025 Gestalt.

Compare Upgrades

Components

Complete component specification list for this variant.

Drivetrain

Front
Front Derailleur
Shimano Claris
Front Derailleur
Gears
2
Front Shifter
Shimano Claris 2-Speed
Front Shifter
Rear
Rear Derailleur
Shimano Claris
Rear Shifter
Shimano Claris 8-Speed
Back Shifter
Chainring
FSA Tempo Compact
Front Chainring
Gears
2
Ring 1
50 Teeth
Ring 2
34 Teeth
Cassette
Sun -Speed
Cassette
Number of sprockets
8
Range
11-32T
Chain
KMC KMC Z
Chain
Gears
8
Crank
FSA Tempo Compact
Crank
Length
170
Bottom Bracket
Sealed Bearing Square Taper

Seat

Saddle
Marin Beyond Road Concept
Saddle
Seatpost
Marin Alloy
Seatpost
Diameter
27.2 mm
Material
Alloy

Cockpit

Stem
Forged Marin 3D
Stem
Length
70 mm
Material
Alloy
Handlebar
Marin Butted , Compact 16º Flared Drop
Handlebar
Width
420 mm
Material
Alloy
Grips
Marin Perforated Tape

Frame

Pedals
Nylon Platform
Pedals
Type
Flat
Frame
Series 2 Beyond Road,
Frame
Material
6061 Aluminum
Fork
6061 Aluminum, Straight-Blade
Fork
Front Axle Dimension
9mm QR

Wheels

Front
Front Tire
WTB Exposure Comp (700C, 36mm)
Front Tire
Size
700C
Width
36mm
Front Wheel
Marin Aluminum Double Wall
Rear
Rear Tire
WTB Exposure Comp (700C, 36mm)
Back Tire
Size
700C
Width
36mm
Rear Wheel
Marin Aluminum Double Wall

Brakes

Front
Front Brake
Tektro MD-C400 Road Mechanical Disc
Front Brake
Front Disc
Tektro MD-C400 Rotor
Front Disc
Diameter
160 mm
Rear
Rear Brake
Tektro MD-C400 Road Mechanical Disc
Back Brake
Rear Disc
Tektro MD-C400 Rotor
Back Disc
Diameter
160 mm
