Marin
DSX FS
2026
DSX FS Data
- MSRP
- EUR 1759.00
- Frame
- 6061 Aluminum
- Suspension
- Hardtail
- Travel
- Front: 60mm
- Gears
- 12
- Sizes
- Small, Medium, Large, Xlarge
- Colors
- Black/ Orange
Looking for replacement tires?
View verified compatible tires for the 2026 DSX FS.
Components
Complete component specification list for this variant.
Drivetrain
Rear Derailleur
Shimano Deore RD-M6100
- Gears
- 12
Chain
KMC X12
- Gears
- 12
Crank
Forged Aluminum
- Length
- 175
Chainring
Forged Aluminum Narrow Wide
- Gears
- 1
- Ring 1
- 42 Teeth
Cassette
Shimano Deore CSM6100
- Number of sprockets
- 12
- Range
- 10-51T
Rear Shifter
Shimano Deore SL-M6100
Bottom Bracket
Sealed Outboard Bearing
Frame
Pedals
Nylon
- Type
- Platform
Frame
Series 3 DSX
- Rear Axle Dimension
- 142x12mm
- Material
- 6061 Aluminum
Fork
Sun SR tour GVX LOR
- Travel
- 60 mm
- Front Axle Dimension
- 100x12mm
- Steer tube diameter
- 1 1/8” x 1 1/2”
- Offset
- 47 mm
Cockpit
Stem
Forged Marin 3D
- Material
- Alloy
Handlebar
Marin MiniRiser
- Width
- 680 mm
Grips
Marin MTB
Seat
Saddle
Marin DSX
Seatpost
TranzX YSP38J
- Diameter
- 27.2 mm
- Dropper post
- 1
- Travel
- 110 mm
Wheels
Front
Front Tire
Vee Tire Co. QuikStyk (700c, 45)
- Size
- 700c
- Width
- 45
Front Wheel
Marin Aluminum Double Wall
Rear
Rear Tire
Vee Tire Co. QuikStyk (700c, 45)
- Size
- 700c
- Width
- 45
Rear Wheel
Marin Aluminum Double Wall
Brakes
Front
Front Brake
Shimano BR-MT201/R300
Front Disc
Shimano
Rear
Rear Brake
Shimano BR-MT201/R300
Rear Disc
Shimano
