Marin
Alcatraz 2026 ALCATRAZ JR. 24'
2026Mountain - Dirt Jump / Slopestyle
Alcatraz 2026 ALCATRAZ JR. 24' Data
- MSRP
- EUR 899.00
- Frame
- Aluminum
- Suspension
- None, Hardtail
- Gears
- 1
- Sizes
- Os
- Colors
- Red Pink
Looking for replacement tires?
View verified compatible tires for the 2026 Alcatraz 2026 ALCATRAZ JR. 24'.
Components
Complete component specification list for this variant.
Brakes
Rear Disc
Tektro Tektro
- Diameter
- 160 mm
Rear Brake
Tektro HD-M280
Cockpit
Stem
Forged Marin 3D Alloy
- Length
- 35 mm
Grips
Marin MTN, Closed End
Handlebar
Marin Riser
Seat
Seatpost
Marin Alloy
- Diameter
- 30.9 mm
Saddle
Marin DJ Saddle
Drivetrain
Bottom Bracket
Sealed External Cartridge Bearings
- Standard
- 73mm Threaded
Chainring
Ring Alloy T DM Chain
- Gears
- 1
- Ring 1
- 32 Teeth
Cassette
Single 4T Speed Cog
- Number of sprockets
- 1
- Range
- 14T
Chain
KMC HL-1
Crank
Forged Marin Alloy
- Length
- 152
Wheels
Front
Front Wheel
Forged Marin Custom Extrusion rim, Alloy hub (100mm)
- Axle Dimension
- 100mm
- Inner width
- 27 mm
- Position
- front
Front Tire
Vee Tire Rail
Rear
Rear Wheel
Forged Marin Custom Extrusion rim, Alloy hub (135x10mm)
- Axle Dimension
- 135x10mm
- Inner width
- 27 mm
- Position
- back
Rear Tire
Vee Tire Rail
Frame
Frame
Series 3 6061
- Rear Axle Dimension
- 135x10mm
- Material
- Aluminum
Fork
Series Marin 2 Cro-Mo 24" Fork
- Front Axle Dimension
- 100x9mm
- Steer tube diameter
- 1 1/8" x 1 1/2"
- Offset
- 44 mm
Pedals
Alloy
- Type
- Platform
Accessories
Chainguard
Marin Chain Tension Device
