STEREO HYBRID ONE22 RACE 800
2025 ElectricE-Mountain - E-Trail
STEREO HYBRID ONE22
RACE 800 Data
- MSRP
- EUR 3999.00
- Frame
- Aluminium Superlite
- Suspension
- Fully, Full Suspension
- Travel
- Front: 120mm, Rear: 120mm
- Gears
- 12
- Weight
- 26.7 kg
- Sizes
- S, M, L, Xl
- Colors
- Shiftblush´n´black
Looking for replacement tires?
View verified compatible tires for the 2025 STEREO HYBRID ONE22 RACE 800.
Components
Complete component specification list for this variant.
Drivetrain
Cassette
Shimano Deore CS-M6100
- Number of sprockets
- 12
- Range
- 10-51T
Rear Derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, -Speed
- Gears
- 12
Rear Shifter
Shimano Deore SL-M6100-R, Rapidfire Plus
Display
Integrated Bosch Purion 200 with Display
Motor
Performance Bosch Drive Unit Line CX max. Nm (BDU38)
- Torque
- 100 Nm
Chainring
ACID MTB Hybrid Pro
- Gears
- 1
- Ring 1
- 38 Teeth
Battery
Bosch PowerTube 800
Chain
KMC e12
Frame
Pedals
ACID PP MTB
- Type
- MTB
Fork
RockShox Psylo Silver RC Air, Tapered, Lockout
- Travel
- 120 mm
- Front Axle Dimension
- 15x110mm
Frame
Integrated Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Battery, Advanced Internal Cable Routing
- Rear Axle Dimension
- 12x148 mm
- Material
- Aluminium Superlite
Rear Shock
RockShox Deluxe Select R, 185x52.5mm, Rebound Adjust, Trunnion Mount
- Travel
- 120 mm
Cockpit
Stem
Performance CUBE Stem E-MTB , FPI-Link
- Length
- 50 mm
- Clamping diameter
- 35 mm
Handlebar
Cube Rise Trail Bar
- Width
- 760 mm
- Clamping diameter
- 35 mm
Grips
ACID Hybrid Perform
Seat
Saddle
ACID Venec EMTB Plus 145
Seatpost
Cube Dropper Post, Handlebar Lever, Internal Cable Routing
- Diameter
- 31.6 mm
- Dropper post
- 1
Accessories
Charger
Bosch Bosch A
- Speed
- 2 A
Chainguard
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Wheels
Front
Front Tire
Schwalbe Smart Sam, Active (2.6)
- Width
- 2.6
Front Wheel
ACID SLX , 32/32 Spokes, Tubeless Ready (15x110mm)
- Axle Dimension
- 15x110mm
- Inner width
- 30 mm
- Position
- front
Rear
Rear Tire
Schwalbe Smart Sam, Active (2.6)
- Width
- 2.6
Rear Wheel
ACID SLX , 32/32 Spokes, Tubeless Ready (12x148mm)
- Axle Dimension
- 12x148mm
- Inner width
- 30 mm
- Position
- back
Brakes
Front
Front Disc
Shimano BR-MT520, Hydr. Disc Brake
- Diameter
- 203 mm
Front Brake
Shimano BR-MT520
Rear
Rear Disc
Shimano BR-MT520, Hydr. Disc Brake
- Diameter
- 203 mm
Rear Brake
Shimano BR-MT520
