Cube
KATHMANDU ONE
2025City & Touring - Touring
KATHMANDU
ONE Data
- MSRP
- EUR 799.00
- Frame
- Aluminium
- Suspension
- Hardtail
- Travel
- Front: 63mm
- Gears
- 18
- Weight
- 17.3 kg
- Sizes
- 50Cm, 46Cm, 62Cm, 54Cm, 58Cm
- Colors
- Sagebrushgreen´n´green
Looking for replacement tires?
View verified compatible tires for the 2025 KATHMANDU ONE.
Components
Complete component specification list for this variant.
Drivetrain
Front
Front Shifter
Shimano Cues SL-U4010- Rapidfire-Plus
Front Derailleur
Shimano Cues FD-U4010, Top-Swing
- Gears
- 2
Rear
Rear Shifter
Shimano Cues SL-U4010- Rapidfire-Plus
Rear Derailleur
Shimano Cues RD-U4020-SGS
- Gears
- 9
Crank
Chainguard Shimano Cues FC-U4010
Chain
KMC xGlide
- Gears
- 9
Chainring
Shimano Cues
Cassette
Shimano CS-LG300
Bottom Bracket
Shimano BB-MT501
Accessories
Front
Front Light
Cube Shiny
- Lumen
- 50 lm
Rear
Rear Light
ACID Mudguard Rear Light PRO-D, 6V, AC
Chainguard
Integrated Shimano Cues
Cockpit
Grips
ACID Travel Comfort
Handlebar
Cube Comfort Trail Bar
- Width
- 680 mm
- Clamping diameter
- 31.8 mm
Stem
CUBE Performance Stem SLX
Wheels
Front
Front Tire
Schwalbe Marathon Green, Perf (622, 47)
- Size
- 622
- Width
- 47
Front Wheel
Shimano ACID EX / DH-3D37 (28", QR)
- Size
- 28"
- Axle Dimension
- QR
- Rotor mount
- Centerlock
- Inner width
- 25 mm
- Material
- Aluminium
Rear
Rear Tire
Schwalbe Marathon Green, Perf (622, 47)
- Size
- 622
- Width
- 47
Rear Wheel
Shimano ACID EX / FH-TC500-HM (28", 12mm Through Axle)
- Size
- 28"
- Axle Dimension
- 12mm Through Axle
- Rotor mount
- Centerlock
- Inner width
- 25 mm
- Material
- Aluminium
Seat
Seatpost
Performance CUBE Post
- Length
- 350 mm
- Diameter
- 27.2 mm
Saddle
ACID Sequence 160
Frame
Frame
Integrated Superlite, Trekking Comfort, Carrier 3.0, Double Butted
- Rear Axle Dimension
- 12x142 mm
- Material
- Aluminium
Fork
Sun SR tour NEX
- Travel
- 63 mm
- Front Axle Dimension
- QR
Pedals
ACID PP Trekking
- Type
- Flat
Brakes
Front
Front Brake
Shimano BR-MT200
Front Disc
Shimano
Rear
Rear Brake
Shimano UR300
Rear Disc
Shimano
