Cube
AIM ONE FE
2026Mountain - Cross-Country (XC)
AIM
ONE FE Data
- MSRP
- EUR 599.00
- Frame
- Aluminium Lite
- Suspension
- Hardtail
- Travel
- Front: 100mm
- Gears
- 8
- Weight
- 17.1 kg
- Sizes
- S, M, L, Xl, Xs
- Colors
- Smoke´n´black
Looking for replacement tires?
View verified compatible tires for the 2026 AIM ONE FE.
Components
Complete component specification list for this variant.
Drivetrain
Front
Front Shifter
Shimano SL-M315, Rapidfire-Plus
Front Derailleur
Shimano FD-M315, Top Swing
Rear
Rear Shifter
Shimano SL-M315, Rapidfire-Plus
Rear Derailleur
Shimano RD-TX800
Cassette
Shimano CS-HG200
- Number of sprockets
- 8
- Range
- 12-32T
Crank
Shimano FC-M315
- Length
- 170
Bottom Bracket
Thun Paso-ML
- Standard
- BSA
Chain
KMC Z8.3
Chainring
Shimano FC-M315
Seat
Saddle
ACID Venec Lite
Seatpost
Performance CUBE Post
- Diameter
- 27.2 mm
Cockpit
Handlebar
Cube Rise Trail Bar
- Width
- 680 mm
Grips
ACID Icon
Stem
CUBE Performance Stem
Wheels
Front
Front Tire
Cube MTB (2.25)
- Width
- 2.25
Front Wheel
Shimano ACID EX25 / DH-3D32, Hub Dynamo
- Rotor mount
- Disc
- Position
- Front
Rear
Rear Tire
Cube MTB (2.25)
- Width
- 2.25
Rear Wheel
ACID EX25 / Pro
- Rotor mount
- 6-Bolt
- Position
- Back
Accessories
Front
Front Light
Cube Shiny 50
Rear
Rear Light
ACID Mudguard Rear Light PRO-D, 6V, AC
Frame
Pedals
Cube PP MTB
- Type
- MTB
Frame
Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Flat Mount Brake, SIC Mount, FM Kickstand Mount
- Material
- Aluminium Lite
Fork
Sun SR tour XCE
- Travel
- 100 mm
Brakes
Front
Front Brake
Shimano BR-MT200/UR300
Front Disc
Shimano
Rear
Rear Brake
Shimano BR-MT200/UR300
Rear Disc
Shimano
