Canyon
Stchd Stitched 360
2026Mountain - Dirt Jump / Slopestyle
Stchd Stitched 360 Data
- MSRP
- EUR 999.00
- Frame
- Aluminium (AL)
- Travel
- Front: 100mm
- Weight
- 12.2 kg
Looking for replacement tires?
View verified compatible tires for the 2026 Stchd Stitched 360.
Components
Complete component specification list for this variant.
Frame
Pedals
included
Frame
HED Stitc 360
- Rear Axle Dimension
- 9x135 mm
- Material
- Aluminium (AL)
Fork
Manitou Circus Sport
- Travel
- 100 mm
- Front Axle Dimension
- 20x110 mm
- Stanchion Diameter
- 32
- Steer tube diameter
- 1 1/8"
- Weight
- 3379 g
Wheels
Front
Front Wheel
Alexrims FR30 | Stitched Hub (20x110 mm)
- Axle Dimension
- 20x110 mm
- Rotor mount
- IS 6-bolt
- Rim height
- 19 mm
- Inner width
- 23 mm
- Material
- Aluminium
- Position
- front
- Weight
- 971 g
Front Tire
Maxxis DTH (2.3")
- Width
- 2.3"
- Weight
- 649 g
Rear
Rear Wheel
Alexrims FR | Stitched Hub (9x135 mm)
- Axle Dimension
- 9x135 mm
- Rotor mount
- IS 6-bolt
- Rim height
- 19 mm
- Inner width
- 30 mm
- Position
- back
- Weight
- 848 g
Rear Tire
Maxxis DTH (2.3")
- Width
- 2.3"
- Weight
- 649 g
Brakes
Rear Disc
SRAM G2 Centerline
- Diameter
- 160 mm
- Weight
- 127 g
Rear Brake
SRAM Level T
Drivetrain
Chainring
Face Aeffect T
- Gears
- 1
- Ring 1
- 30 Teeth
Chain
KMC Connection Link s
- Gears
- 1
Crank
Face Aeffect 30T
Bottom Bracket
Face BSA
- Standard
- BSA 68/73
- Weight
- 100 g
Cockpit
Stem
Face Chester
- Fork steer tube diameter
- 1 1/8"
- Clamping diameter
- 35 mm
Handlebar
Face Chester Riserbar
Grips
Canyon Stitched
Seat
Saddle
Canyon Stitched
- Gender
- Unisex
- Weight
- 581 g
Seatpost
Canyon Stitched
- Length
- 260 mm
- Diameter
- 27.2 mm
- Material
- Aluminium (AL)
- Weight
- 395 g
Seatpost Clamp
Canyon Clamp SL
