BikeDB
BMC

Kaius 01 ONE

2026Gravel
Kaius 01 ONE Data
MSRP
CHF 10999.00
Frame
Carbon
Gears
13
Weight
7.5 kg
Colors
Acid Yellow / River Blue
EAN
7630906523360
View on BMC

Components

Complete component specification list for this variant.

Brakes

Front
Front Disc
SRAM Paceline X | Centerlock
Front Disc
Diameter
160 mm
Front Brake
SRAM Red AXS (ED-RED-E1)
Front Brake
Rear
Rear Disc
SRAM Paceline X | Centerlock
Back Disc
Diameter
160 mm
Rear Brake
SRAM Red AXS (ED-RED-E1)
Back Brake

Drivetrain

Chain
SRAM RED (CN-RED-E1)
Chain
Gears
12
Rear Shifter
SRAM Red AXS (ED-RED-E1)
Back Shifter
Chainring
SRAM Red XPLR AXS DUB Wide E (Chainrings: T)
Front Chainring
Gears
1
Ring 1
42 Teeth
Rear Derailleur
SRAM Red XPLR AXS (RD-RED-1E-E1)
Back Derailleur
Gears
13
Cassette
SRAM Red XPLR (CS-XG-91-E1)
Cassette
Number of sprockets
13
Range
10-46T
Crank
SRAM Red XPLR AXS DUB Wide E1
Crank
Bottom Bracket
SRAM Press Fit DUB
Bottom bracket

Wheels

Front
Front Wheel
CG SL | Tubeless Ready | mm (12 x 100mm Thru-Axle)
Front Wheel
Axle Dimension
12 x 100mm Thru-Axle
Rotor mount
Center Lock
Rim height
39 mm
Material
Carbon
Position
Front
Front Tire
Pirelli Cinturato Gravel H (40mm)
Front Tire
Width
40mm
Rear
Rear Wheel
CG SL | Tubeless Ready | mm (12 x 142mm Thru-Axle)
Back Wheel
Axle Dimension
12 x 142mm Thru-Axle
Rotor mount
Center Lock
Rim height
39 mm
Material
Carbon
Position
Rear
Rear Tire
Pirelli Cinturato Gravel H (40mm)
Back Tire
Width
40mm

Frame

Frame
Kaius 01 Premium with Aerocore Design | ICS Technology Stealth Cable Routing | UDH Dropout | TCC Race Compliance Level | Flat Mount Disc
Frame
Rear Axle Dimension
12 x 142mm Thru-Axle
Tyre clearance
44 65
Material
Carbon
Fork
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc
Fork
Front Axle Dimension
12 x 100mm Thru-Axle

Cockpit

Handlebar
ICS Aero | One-Piece Full Cockpit | mm drop, mm reach, ° flare
Handlebar
Angle
12.5 °
Material
Carbon
Drop
135 mm
Reach
77 mm

Seat

Saddle
Fizik Vento Argo X1 Carbon | 140mm
Saddle
Seatpost
Kaius 01 Premium D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Seatpost
Material
Carbon

This is the only variant

No other variants available for comparison

Replacement Parts

Find compatible wear items and replacement parts for your bike. Components are organized by category to help you maintain and upgrade your ride.

Drivetrain

Maintain optimal power transfer with the correct drivetrain components for your Kaius 01 ONE. We recommend adhering to manufacturer standards for best shifting performance, though compatible third-party options exist for upgrades or budget repairs.

No resources available yet

Chain
Chain
Recommended OEM Spec:
SRAM RED (CN-RED-E1)
Front Chainring
Front Chainring
Recommended OEM Spec:
SRAM Red XPLR AXS DUB Wide E (Chainrings: T)
Back Derailleur
Back Derailleur
Recommended OEM Spec:
SRAM Red XPLR AXS (RD-RED-1E-E1)
Cassette
Cassette
Recommended OEM Spec:
SRAM Red XPLR (CS-XG-91-E1)
Bottom bracket
Bottom bracket
Recommended OEM Spec:
SRAM Press Fit DUB

Brakes

Ensure safe stopping power with the right brake components for your Kaius 01 ONE. OEM parts guarantee compatibility, while aftermarket alternatives can offer performance upgrades or cost savings.

No resources available yet

Front Disc
Front Disc
Recommended OEM Spec:
SRAM Paceline X | Centerlock
Back Disc
Back Disc
Recommended OEM Spec:
SRAM Paceline X | Centerlock
Front Brake
Front Brake
Recommended OEM Spec:
SRAM Red AXS (ED-RED-E1)
Back Brake
Back Brake
Recommended OEM Spec:
SRAM Red AXS (ED-RED-E1)

Tires & Tubes

Keep your Kaius 01 ONE rolling smoothly with properly matched tires and tubes. The recommended specs ensure optimal grip, puncture protection, and ride quality for your specific setup.

No resources available yet

Front Tire
Front Tire
Recommended OEM Spec:
Pirelli Cinturato Gravel H (40mm)
Back Tire
Back Tire
Recommended OEM Spec:
Pirelli Cinturato Gravel H (40mm)

Suspension & Bearings

Maintain your Kaius 01 ONE's suspension performance with the correct bearings and service parts. Regular maintenance ensures consistent handling and extends component life.

No resources available yet

Fork
Fork
Recommended OEM Spec:
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc

Cockpit

Customize your Kaius 01 ONE's cockpit with compatible handlebars, stems, and grips. These contact points affect comfort, control, and overall riding experience.

No resources available yet

Handlebar
Handlebar
Recommended OEM Spec:
ICS Aero | One-Piece Full Cockpit | mm drop, mm reach, ° flare
Saddle
Saddle
Recommended OEM Spec:
Fizik Vento Argo X1 Carbon | 140mm
Seatpost
Seatpost
Recommended OEM Spec:
Kaius 01 Premium D-Shaped Seatpost | 15mm Offset | D-Fender Compatible

Wear Items

Replace high-wear items on your Kaius 01 ONE regularly to maintain performance and safety. These components see frequent use and benefit from periodic replacement.

No resources available yet

Saddle
Saddle
Recommended OEM Spec:
Fizik Vento Argo X1 Carbon | 140mm

Accessories

Compatible accessories matched to your bike's specifications. Find the perfect upgrades and add-ons.

No compatible accessories found

Accessories are matched based on bike specifications
